Description
| PRODUCT NUMBER | MLX-D24M-A18P2-R1 |
| EXTERIOR COLOR | BLACK |
| CPU SOCKET | LGA2066, LGA2011-V3, LGA2011, LGA1700*, LGA1200, LGA1151, LGA1150, LGA1155, LGA1156, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1 |
| RADIATOR MATERIAL | ALUMINUM |
| RADIATOR DIMENSIONS | 277 X 119.6 X 27.2 MM / 10.9 X 4.7 X 1.1 INCH |
| PUMP DIMENSIONS | 81.4 X 76 X 57.8 MM / 3.2 X 3 X 2.3 INCH |
| PUMP MTTF | 70,000 HOURS |
| PUMP NOISE LEVEL | < 10 DBA |
| PUMP CONNECTOR | 3-PIN |
| PUMP RATED VOLTAGE | 12 VDC |
| PUMP POWER CONSUMPTION | 2.36 W |
| FAN DIMENSIONS (L X W X H) | 120 X 120 X 25 MM / 4.7 X 4.7 X 1 INCH |
| FAN QUANTITY | 2 PCS |
| FAN LED TYPE | ADDRESSABLE GEN 2 RGB |
| FAN SPEED | 650-1800 RPM ± 10% |
| FAN AIRFLOW | 47.2 (MAX) |
| FAN NOISE LEVEL | 6 – 30 DBA |
| FAN PRESSURE | 1.60 MMH₂O (MAX) |
| FAN LIFE EXPECTANCY | 160,000 HOURS |
| FAN POWER CONNECTOR | 4-PIN (PWM) |
| FAN RATED VOLTAGE | 12VDC |
| FAN RATED CURRENT | 0.25A |
| RAM CLEARANCE | N/A |
| WARRANTY | 3 YEARS |
| SERIES | MASTERLIQUID |
| COOLER TYPE | LIQUID COOLER |
| RADIATOR SIZE | 240 |
| NOTE | *LGA1700 MOUNTING KIT INCLUDED IN PRODUCTS WITH NEW PACKAGING DESIGN. YOU MAY OBTAIN REQUIRED MOUNTING KITS FOR PRODUCTS WITH OLDER PACKAGE DESIGN THROUGH CM STORE OR REGIONAL RESELLERS AND DISTRIBUTORS. |
