Description
RVZ03-ARGB Feature list
| Motherboard RGB default mode description | |
|---|---|
| ASROCK | When RGB devices are connected without software, some models will display single color while others will default to multi-color animation display. |
| ASUS | When RGB devices are connected without software, they will default to multi-color demo mode. |
| BIOSTAR | When RGB devices are connected without software, they will default to blue color display. |
| Gigabyte | When RGB devices are connected without software, some models will display single color while others will default to multi-color animation display. |
| MSI | When RGB devices are connected without software, they will default to single color display. |
SPECIFICATIONS
| Model No. | SST-RVZ03B-ARGB (black) SST-RVZ03W-ARGB (white) | |
| Material | Reinforced plastic outer shell, steel body | |
| Motherboard | Mini-DTX, Mini-ITX | |
| Drive bay | External | — |
| — | ||
| Internal | 2.5” x 3 | |
| Cooling system | Front | — |
| Rear | — | |
| Side | — | |
| Top | 1 x 120mm fan, 1500rpm, 18dBA | |
| Bottom | 1 x 120mm fan, 1500rpm, 18dBA 1 x 120mm fan slot | |
| Internal | — | |
| Expansion slot | 2 | |
| Front I/O port | USB3.0 x 2 Audio x 1 MIC x 1 | |
| Power supply | Optional PS2(ATX) | |
| Expansion card | Compatible up to 13″ (330mm) long, width restriction-5.88″ (149mm) | |
| Limitation of CPU cooler | 83mm | |
| Limitation of PSU | 150mm* | |
| Net weight | 4.05 kg | |
| Dimension | 382mm (W) x 105mm (H) x 364mm (D), 14.6 Liters 15.04″ (W) x 4.13″ (H) x 14.33″ (D), 14.6 Liters | |
| Extra | Support Kensington lock PCI Express riser card set x 1 ARGB control PCB x 1 | |
| Remark |
* Maximum length for power supply is 150mm but we recommend 140mm deep power supply due to varying connector locations and the unique structure of RVZ03. Due to the use of internal power cord extension, we recommend not to exceed 800W when powering off a 110V outlet (no limit for 220V). |
