MSI Pro B660 A DDR4 Intel Motherboard Windows 11 Compatible

14,200.00 (In. GST)

PRO B660-A DDR4

  • Supports 12th Gen Intel® Core™, Pentium® Gold, and Celeron® processors for LGA 1700 socket
  • Supports DDR4 Memory, up to 4800+(OC) MHz
  • Lightning Fast Experience: PCIe 4.0 slots, Lightning Gen4 x4 M.2 with M.2 Shield Frozr
  • Premium Thermal Solution: Extended Heatsink Design, MOSFET thermal pads rated for 7W/mk, and M.2 Shield Frozr are built for high-performance system and non-stop works
  • 2.5G LAN: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
  • Turbo USB 3.2 Gen 2: Powered by a USB 3.2 Gen2 controller, Turbo USB ensures an uninterrupted connection with more stability and the fastest USB speeds
  • High-Quality PCB: 6-layer PCB made by 2oz thickened copper level material
  • Multi-GPU: With Steel armor PCI-E slots. Supports AMD Crossfire™
  • Audio Boost: Reward your ears with studio grade sound quality

2 in stock

Compare
SKU: NG01042 Categories: ,

Description

MSI Pro B660 A DDR4 Intel Motherboard Windows 11 Compatible

MSI Pro B660 A DDR4 Intel MotherboardMSI Pro B660 A DDR4 Intel Motherboard-1

MSI Pro B660 A DDR4 Intel Motherboard Windows 11 Compatible

THERMAL SOLUTION FOR MORE CORES AND HIGHER PERFORMANCE

With more cores’ processors, thermal and power design is more important to make sure the temperature keeps lower. MSI extended PWM heatsink with 7W/mK thermal pad ensures even high-end processors to run in full speed with MSI motherboards.



HIGH-BANDWIDTH AND LOW-LATENCY NETWORK

2.5Gbps LAN provides incredible data transfer speed faster than general Gigabit LAN. This is a premium solution for demanding users.



LIGHTNING GEN 4 PCI-E

MSI lightning Gen 4 PCI-E is the latest and the fastest PCI-E data transfer solution with 64GB/s of transfer bandwidth that has doubled compared to its previous generation. PCIe 4.0 maintains both backward and forward compatibility with older and newer specifications. Optimized by steel armor design, your motherboards can support the weight of heavy graphics cards.

A HUGE STEP OF DDR PERFORMANCE

MSI OC LAB does not merely work hard on extreme overclocking. The XMP memory profile has great improvement on performance and efficiency for Z690 . Easy to enable XMP profile with auto power settings to get the best memory speed and stability.



CORE BOOST

Core Boost technology combines MSI’s premium layout and optimized power design which allows for faster and undistorted current delivery to the CPU at pinpoint precision. Not only supports multi-core CPU, but also creates the perfect conditions for your CPU overclocking.

MSI Pro B660 A DDR4 Intel Motherboard Windows 11 Compatible

SPECIFICATION

CPU (MAX SUPPORT) i9
SOCKET 1700
CHIPSET Intel® B660 Chipset
DDR4 MEMORY 4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC) MHz
MEMORY CHANNEL Dual
DIMM SLOTS 4
MAX MEMORY (GB) 128
PCI-E X16 2
PCI-E X1 3
SATAIII 4
M.2 SLOT 2
RAID 0/1/5/10
TPM (HEADER) 1
LAN 1x Realtek® RTL8125BG 2.5Gbps LAN controller
USB 3.2 PORTS (FRONT) 1(Gen 1, Type C), 2(Gen 1, Type A)
USB 3.2 PORTS (REAR) 1(Gen 2, Type C), 2(Gen 2, Type A)
USB 2.0 PORTS (FRONT) 2
USB 2.0 PORTS (REAR) 4
AUDIO PORTS (REAR) Realtek® ALC897 Codec
DISPLAYPORT 1
VGA 1
HDMI 1
DIRECTX 12
CROSSFIRE Y
OPERATING SYSTEM Support for Windows® 11 64-bit, Windows® 10 64-bit
FORM FACTOR ATX



MSI Pro B660 A DDR4 Intel Motherboard Windows 11 Compatible
