Intel Core i7 12700F Processor

40,533.00 (In. GST)

25M Cache, up to 4.90 GHz

  • Intel® Core® i7 3.60 GHz processor offers more cache space and the hyper-threading architecture delivers high performance for demanding applications with better onboard graphics and faster turbo boost
  • The Socket LGA-1700 socket allows the processor to be placed on the PCB without soldering
  • 11 MB L2 and 25 MB L3 cache offers supreme performance for computation-intensive apps
  • Intel 7 Architecture enables improved performance per watt and microarchitecture makes it power-efficient

2 in stock

SKU: NG00984 Category:

Description

SPECIFICATION

Intel Core i7-12700F Processor  (25M Cache- up to 4.90 GHz)
Essentials
Product Collection12th Generation Intel® Core™ i7 Processors
Code NameProducts formerly Alder Lake
Vertical SegmentDesktop
Processor Numberi7-12700F
CPU Specifications
Total Cores12
# of Performance-cores8
# of Efficient-cores4
Total Threads20
Max Turbo Frequency4.90 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency4.90 GHz
Performance-core Max Turbo Frequency4.80 GHz
Efficient-core Max Turbo Frequency3.60 GHz
Performance-core Base Frequency2.10 GHz
Efficient-core Base Frequency1.60 GHz
Cache25 MB Intel® Smart Cache
Total L2 Cache12 MB
Processor Base Power65 W
Maximum Turbo Power180 W
Memory Specifications
Max Memory Size (dependent on memory type)128 GB
Memory TypesUp to DDR5 4800 MT/s Up to DDR4 3200 MT/s
Max # of Memory Channels2
Max Memory Bandwidth76.8 GB/s
Expansion Options
Direct Media Interface (DMI) Revision4
Max # of DMI Lanes8
PCI Express Revision5.0 and 4.0
PCI Express Configurations ‡Up to 1×16+4 |  2×8+4
Max # of PCI Express Lanes20
Package Specifications
Sockets SupportedFCLGA1700
Max CPU Configuration1
Thermal Solution SpecificationPCG 2020C
TJUNCTION100°C
Package Size45.0 mm x 37.5 mm
Advanced Technologies
Intel® Gaussian & Neural Accelerator3
Intel® Thread DirectorYes
Intel® Deep Learning Boost (Intel® DL Boost)Yes
Intel® Optane™ Memory Supported ‡Yes
Intel® Speed Shift TechnologyYes
Intel® Turbo Boost Max Technology 3.0 ‡Yes
Intel® Turbo Boost Technology ‡2
Intel® Hyper-Threading Technology ‡Yes
Intel® Virtualization Technology (VT-x) ‡Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡Yes
Intel® VT-x with Extended Page Tables (EPT) ‡Yes
Intel® 64 ‡Yes
Instruction Set64-bit
Instruction Set ExtensionsIntel® SSE4.1 |  Intel® SSE4.2 |  Intel® AVX2
Idle StatesYes
Enhanced Intel SpeedStep® TechnologyYes
Thermal Monitoring TechnologiesYes
Intel® Volume Management Device (VMD)Yes
Security & Reliability
Intel® AES New InstructionsYes
Secure KeyYes
Intel® OS GuardYes
Execute Disable Bit ‡Yes
Intel® Boot GuardYes
Mode-based Execute Control (MBEC)Yes
Intel® Control-Flow Enforcement TechnologyYes
